| DL-0828-25M-JT | Working distance (mm) | Optical Magnification | 1.1" Field of View(mm) | |||||
| H | V | |||||||
| 100 | 0.083X | 170.8 | 125.1 | |||||
| Focal length | 8mm | Distortion(TV) | <0.38% | 150 | 0.055X | 256.2 | 187.7 | |
| Compatible resolution | 10MP/12MP/20MP | Adjustment mode | Manual | 200 | 0.041X | 341.6 | 250.2 | |
| Sensor Size | 1.1" | Filter screw size | M72X0.75 | 250 | 0.033X | 427.0 | 312.8 | |
| Max Diameter(RATIO) | F2.8-F12 | Working Temperature | -10℃~+50℃ | 300 | 0.028X | 512.4 | 375.3 | |
| Working distance | 0.1m-∞ | Storage Temperature | -20℃~+60℃ | 350 | 0.024X | 597.8 | 437.9 | |
| Mount | C-Mount | Weight | 0.21kg | 400 | 0.021X | 683.2 | 500.4 | |
| sensor | 1.1"(14.1x10.3) | 1"(14.1x7.5) | 2/3"(8.4x7.1) | 450 | 0.018X | 768.6 | 563.0 | |
|
Fov Angle | D | 93.6° | 88° | 67.4° | 500 | 0.017X | 854.0 | 625.5 |
| H | 81° | 80.9° | 53.9° | 550 | 0.015X | 939.4 | 688.1 | |
| V | 64.1° | 48.4° | 46.1° | 600 | 0.014X | 1024.8 | 750.6 | |
