| Focal Length | 8mm | FOV(H×V) | 1/1.7" | 50.42°× 38.80° |
| Image Format | 1/1.7" | 1/2.3" | 43.68°× 32.01° | |
| Iris Range | F2.8 ～ F16 | 1/2.5" | 39.23°× 29.93° | |
| Focus Range | 0.05m ～ Inf. | Filter Size | M25.5 ,P=0.5mm | |
| TV Distortion | -0.15%@0.5m | Dimensions | Φ29×29.4mm | |
| Iris Type | Manual | Weight | 46±2g | |
| Mount | C-Mount | Temperature Range | -20℃ ～ 70℃ | |
